Charger-PRO3

N12 Battery Charger Instructions – Rapid Release® N12 Battery Charger
Before using this appliance, read these instructions carefully.

Safety Rules for Rapid Release® Charger

Suitable for Rapid Release Battery 10.8V–12V Li-ion

1. Protect the battery charger from rain and moisture. Water penetration increases the risk of electric shock.
2. Do not charge other batteries. This charger is suitable only for matched lithium-ion batteries within the listed voltage range — using other batteries creates a danger of fire and explosion.
3. Keep the battery charger clean. Contamination may increase the risk of electric shock.
4. Before using, always check the charger, cable, and plug. If defects are detected, do not use the charger and never attempt to open it.
5. Have the charger repaired only by qualified personnel using original spare parts. Damaged chargers, cables, and plugs increase the risk of electric shock.
6. Do not operate the charger on easily flammable surfaces (e.g., paper, textiles) or in combustible surroundings. Heat generated during charging may cause a fire.
7. Plug the charger only within the listed voltage range printed on the charger.
8. Unplug the charger from the electrical outlet before any maintenance or cleaning to reduce the risk of electric shock.
9. Disconnect the charger from the power supply when not in use to reduce risk of electric shock or damage if metal items fall into the opening.
10. Do not touch the un-insulated portion of the output connector or un-insulated battery terminal — risk of electric shock.
11. This appliance is not intended for use by persons with reduced physical, sensory, or mental capabilities, or lack of experience, unless supervised or instructed by a person responsible for their safety.
12. Children should be supervised to ensure they do not play with the appliance.
13. If the power cord is damaged, do not attempt to repair it yourself — return it to our service organization or a qualified technician.
14. Do not charge a damaged or unusable battery.

Operation

Battery Charging

Charge indoors only.

• This charger is suitable for charging N12 battery packs.
• Rated voltage range: 100–240VAC, 50/60Hz.
• Maximum charge current: 3A.
• Built-in protection functions include: overvoltage, overcurrent, overload, short circuit, and reverse current protection.
• Intelligent battery voltage detection automatically identifies whether a battery pack is good or bad.
• Charger lifespan: 10,000+ hours under rated input voltage and mean output current.
• Operating environment: -20°C to 40°C, humidity 20%–85%.

Operation Instructions – Indicator Light Guide

• Solid green light (no battery inserted): Charger is ready and functioning normally.
• Green flashing light (battery inserted): Battery is charging.
• Solid green light (battery inserted): Battery is fully charged — unplug promptly.
• Red and green lights flashing alternately: The battery pack is bad or unusable.
• Solid red light: The charger is bad — discontinue use and contact support.
